Specs

UPC

193308242323

Width / Cutting Deck

72"

Drive

Hydro-Drive

Starter

Electric

Steering Control

Hydraulically dampened twin levers adjustable both fore and aft. Also has 2-position height adjustment. Adjustable dampers (3 positions) to customize drive responsiveness

Caster Forks

.50" thick caster yoke arms.

Front Caster Tires

13 x 6.5-6, smooth tread, semi-pneumatic

Drive Tires

24 x 12-12, 4 ply Grassmaster TL

Safety Package

Operator Presence Controls (OPC) and drive system interlock, with safety interlock system indicators.

Parking Brake

Lever actuated disc brake

Tractor Frame

Unibody, welded, heavy-duty 1.5" x 3" tubular steel.

Blade Spindles

No maintenance, sealed and non-greasable spindles; 7.75"-diameter cutter housing with 25mm (.98") diameter spindle shaft and splined blade driver.

Electrical

12-volt battery with 20-amp alternator.

Standard Features

Engine hour meter and cup holder

Seat

Deluxe, bolstered suspension seat with Elastomeric Vibration Control material. Adjustment: Fore and aft from Operators’ Position.

Engine Brand

Kohler

Transmission Speeds

Infinitely Variable

Engine Model

ECV749

Engine Displacement

747

Engine Series

Command™ EFI

Speed

Infinitely variable speed selection from 0–10.0 mph (16.1 kmph) forward, 0–7.0 mph (11.3 kmph) reverse

Engine Spec

ECV749

Engine Speed

3,750 RPM

Air Filter

Heavy-duty canister air filtration system

Fuel Capacity

12-gallon single fuel tank with single fill location

Drive Description

Two Exmark exclusive Parker unitized pump and wheel motor systems with no hoses, integrated cooling fans, shock valve, 1.7-quart integrated reservoir, spin-on filter and heavy-duty components. 12 cc pumps and 17.1 cubic inch motors.

Fuel Type

Gas EFI

PTO Engagement

MagStop electromagnetic 200-ft-lb clutch with spot brake

Drive Wheel Release

Allows unit movement without engine running.

Fuel Indicator

Yes - electronic Sender

Deck Lift

Standard; foot-controlled deck lift changes cutting height and lifts the deck to maneuver around obstacles, or place in transport position.

Carb Compliant

Yes

ROPS

2-post foldable ROPS standard with seat belt and latch.

Deck Style

Floating Deck

Deck Style Description

Full-floating UltraCut Series 4. Side discharge standard, with molded discharge chute and option to bag or mulch.

Deck Construction

10-gauge top that is formed and continuously seam welded, 7-gauge side skirt and 7-gauge formed and welded spindle mounting locations for improved strength and reduced weight.

Cutting Heights

1.0" to 5.5" in 0.25" increments

Blade Tip Speed

Approximately 18,500 fpm

Blades

3 Blades at 24.50" Length

Width

84.9"

Height

70.5"

Curb Weight

1250

Length

86.1"
