Specs
UPC
193308000572
Onboard Intelligence
Smart Controller
Starter
Electric
Steering Control
Hydraulically dampened twin levers, adjust fore and aft. Adjustable dampeners (3 positions) to customize drive responsiveness. Also adjustable to 2 height positions.
Caster Forks
.50" thick caster yoke arms.
Front Caster Tires
13 x 6.5-6, smooth-tread, semi-pneumatic.
Drive Tires
24 x 12-12, 4 ply Turf Master®
Parking Brake
Lever-actuated disc brake.
Tractor Frame
Unibody, welded, heavy-duty 1.5" x 3" tubular steel.
Blade Spindles
No maintenance, sealed and non-greasable spindles; 7.75"-diameter cutter housing with 25mm (.98") diameter spindle shaft and splined blade driver.
Electrical
12-volt battery with 20-amp alternator.
Standard Features
Engine hour meter and cup holder
Seat
Deluxe, two-tone, bolstered suspension seat with Elastomeric Vibration Control material. Mounted on innovative Seat Isolation System that provides operator isolation in all three planes of motion as well as fore-aft slide and seat flip-up.
Engine Brand
Kohler
Transmission Speeds
Infinitely Variable
Engine Model
ECV749
Engine Displacement
747
Transmission
Hydrostatic
Engine Series
Command™ EFI
Speed
Infinitely variable speed selection from 0–10.0 mph (16 kmph) forward, 0–6.0 mph (9.7 kmph) reverse.
Drive
Hydro-Drive
Engine Spec
3064
Engine Speed
3,750 RPM
Air Filter
Heavy-duty canister air filtration system
Fuel Capacity
12-gallon (45.4-L), single fuel tank with single fill location.
Drive Description
Two Exmark exclusive Parker unitized pump and wheel motor systems with no hoses, integrated cooling fans, 1.7-quart integrated reservoir, spin-on filter and heavy-duty components. 12 cc pumps and 14. 5 cubic inch motors.
Fuel Type
Gas EFI
PTO Engagement
MagStop electromagnetic 200-ft-lb clutch with spot brake
Drive Wheel Release
Allows unit movement without engine running.
Fuel Indicator
Yes - electronic Sender
Deck Lift
Standard; foot-controlled deck lift changes cutting height and lifts the deck to maneuver around obstacles, or place in transport position.
Carb Compliant
No
Safety Package
Operator Presence Controls (OPC) and drive system interlock, with safety interlock system indicators.
ROPS
2-post foldable ROPS standard with seat belt and latch.
Deck Style
Floating Deck
Deck Style Description
Full-floating UltraCut Series 4. Side discharge standard, with molded discharge chute and option to bag or mulch.
Width / Cutting Deck
60"
Deck Construction
10-gauge top that is formed and continuously seam welded, 7-gauge side skirt and 7-gauge formed and welded spindle mounting locations for improved strength and reduced weight.
Cutting Heights
1.0" (2.5 cm) to 5.5" (11.8 cm) in 0.25" (0.64 cm) increments adjustable from operator’s seat.
Blade Tip Speed
Approximately 18,500 fpm.
Blades
3 Blades at 20.50" Length
Width
72.8 in. (184.9 cm)
Height
70.5 in. (179.1 cm)
Length
83.1 in. (211.1 cm)
Curb Weight
1177
