- Blade Spindles No maintenance, sealed and non-greasable spindles; 7.75"-diameter cutter housing with 25mm (.98") diameter spindle shaft, double row bearings, top and bottom, and splined blade driver.
- Drive Tires 26x12-12, 6ply
- Front Caster Tires 15 x 6.0-6, smooth-tread, semi-pneumatic.
- Caster Forks .50" thick caster yoke arms.
- Tractor Frame Welded, heavy-duty 1.5" x 3" x 3/16" tubular steel.
- Steering Control Hydraulically dampened twin levers, adjust fore and aft., also adjustable to 2 height positions. Adjustable dampeners (3 positions) to customize drive responsiveness.
- Parking Brake Lever-actuated internal wet disc brake.
- Seat Deluxe, two-tone, bolstered suspension seat with Elastomeric Vibration Control material. Mounted on innovative Seat Isolation System that provides operator isolation in all three planes of motion as well as fore-aft slide and seat flip-up.
- Electrical 12-volt battery with 55-amp alternator.
- Onboard Intelligence RED Technology
- Standard Features 12-volt plug-in, engine hour meter and cup holder
- UPC 193308000824
- Engine Brand Yanmar
- Engine Model 3TNV88C
- Engine Displacement 1642
- Engine Series TNV
- Fuel System Common Rail Diesel
- Engine Speed 3,000 RPM
- Air Filter Heavy-duty canister air filtration system with electronic vacuum sensor
- Fuel Type Diesel
- Fuel Capacity 12-gallon (45.4-L), side fuel tanks
- Fuel Indicator Yes - mechanical float type
- Drive Hydro-Drive
- Drive Description Kanzaki KPS-18T Transmission, 16-quart oil capacity, spin-on filter. 18 cc shoe type pumps and 17.84 cubic inch Hydro-Gear HGM-18 motors, hydraulic oil cooler.
- Speed Infinitely variable speed selection from 0–12.5 mph (20 kmph) forward, 0–7 mph (11 kmph) reverse.
- Carb Compliant Yes
- Deck Lift Hydraulic
- Safety Package Operator Presence Controls (OPC) and drive system interlock, with safety interlock system indicators.
- ROPS 2-post foldable ROPS standard with seat belt and latch.
- PTO Engagement Integrated wet clutch system in transmission, connected to right angle gearbox on deck via drive shaft
- Drive Wheel Release Allows unit movement without engine running.
- Engine Spec DTR5
- Width / Cutting Deck 96"
- Deck Style Floating Deck
- Deck Style Description Full-floating UltraCut Rear Discharge Deck. Rear-discharge standard with finish cut baffles included.
- Deck Construction 7-gauge high strength alloy top that is formed and continuously seam welded, with 7-gauge high strength alloy side skirt.
- Blade Tip Speed Approximately 18,500 fpm
- Cutting Heights 1.0" (2.5 cm) to 5.5" (11.8 cm) in 0.25" (0.64 cm) increments.
- Blades 4 Blades at 24.50" Length
- Width 101.2 in. (257.0cm), 72.5 in. @ 3 in. HOC when folded
- Length 97.2 in. (246.9 cm)
- Height 71.8 in. (182.4 cm)
- Curb Weight 2650
